uPVC Window greenEvolution Flex 3D

Brand: Salamander

What you get

6- chamber profile with 3 gaskets
The system adapted to the requirements of passive construction
The use of the central MD gasket

Add to Compare

Specifications
Description
Colours
Pricelist
Files to download
Recently viewed products
Realizations
Similar products

Specifications

Number of chambers	6
Depth of the frame [mm]	76
U-value	0.79
Maximum thickness of the glazing unit [mm]	48
Opening direction	Inwards
Number of gaskets	3
Acoustic insulation	47 dB
Brand	Salamander

Opening direction

There are two window opening directions possible: inwards or outwards. When you want to determine the window opening direction, you have to stand at the side where you can see the hinges. If you are standing outside the building and the windows open towards you, these are outward-opening windows. If, on the other hand, you are standing inside the building and the windows open towards you, these are inward-opening windows.

Thickness of the glazing unit

A glazing unit is a structure consisting of two, three, or even four panes of glazing separated from each other by a distance frame, sealants and vapour-absorbing gas (argon \ krypton). The thickness of the glazing unit is the overall measurement, from the outside glass surface to the inside glass surface. The average double glazing thickness is about 24 mm while triple-glazed windows are 42 – 48 mm in thickness on average. The number of panes in a glazing unit affects the improvement of the U-value parameter

Number of chambers

The number of chambers in the window affects the thermal insulation of the window. The chambers keep air from circulating and in this way they create an additional insulating layer. Energy-saving (passive) windows most often come with a 6-chamber structure and a built-in depth of over 80 mm. Window chambers also increase the structural strength of a window and add to its overall stiffness

Number of gaskets

window gaskets prevent draughts and water from entering into your home. They are also a barrier for the outside noise and an effective way to keep warm air in – and thus, lower your energy bills. Two gaskets are necessary for the window to fulfil its function properly, while the central (third) gasket is not necessary. However, it has been proven that window structures with a central gasket are tighter, both in terms of air permeability and water-tightness, than structures without a middle gasket. Also, third gasket affects the improvement of the U-value parameter.

Uw (U-value)

The window’s heat transfer coefficient. It informs you about the level of window thermal insulation. The Uw (U- value) shows how much heat will penetrate 1 m2 of a window in one hour, with a difference between the temperatures on both sides of the window of one degree. This means that the lower the Uw coefficient, the better the window’s thermal insulation is.

Acoustic insulation (Rw)

Acoustic insulation coefficient. It determines the insulation of the window against noise from the outside. The unit of measurement is decibels (dB). This parameter is influenced by: the thickness of the glazing in the glazing unit, the use of PVB laminated glass or the use of an acoustic foil.

Depth of the frame

A very important dimension, saying a lot about window quality and functionality. The depth affects the sound insulation, thermal insulation (U-value) and stiffness of the structure. To put it simply: the bigger the depth, the warmer the window. In general, deeper window profiles also have more chambers. Standard depths: 5-chamber profiles: 70 mm, 6-chamber profiles: > 70 mm – 90 mm.

greenEvolution Flex 3D is a new solution in the field of energy-saving PVC windows, adapted to the requirements of passive construction. It allows to significantly reduce heat losses and thus, reduce heating bills and the carbon footprint. Better parameters have been achieved thanks to the use of the central MD gasket, which improves the tightness of the window. The classic shape of the profiles, combined with a wide range of available veneers, guarantee easy adaptation to every type and style of a building.

greenEvolution Flex 3D:

6- chamber profile
Window stopper and central gasket
Construction depth: 76 mm
Up to Uw = 0.79 W/(m²K)
Glazing up to 48 mm
Maximum dimensions of the window sash: H up to 2600 mm, L up to 1500 mm
Sound insulation: Sound reduction up to 47 dB
Burglar resistance up to RC 3

Colours

Standard colours

SAL 03

SAL 11

SAL 18

SAL 19

SAL 21

SAL 25

SAL 26

SAL 27

SAL 33

SAL 37

SAL 41

SAL 42

SAL 43

SAL 50

SAL 51

SAL 52

SAL 55

SAL 59

SAL 67

SAL 69

SAL 71

SAL 72

SAL 73

SAL 74

SAL 78

SAL 84

SAL 87

SAL 88

SAL 90

SAL 92

SAL 93

SAL 94

SAL 98

SAL 107

SAL 108

SAL 109

SAL 110

SAL 112

SAL 113

SAL 115

SAL 116

Price list

The prices shown in the Price List are for white, double-glazed and/or triple-glazed products and do not include accessories or custom sizes and dimensions. Additionally, each colour change affects the final price of the product in the following way:

Aluminium windows and sliding systems:

The Customer pays 3-5% more for a one-sided coating or two-sided coating.

uPVC windows:

The Customer pays 10-20% more for a one-sided veneer and 25-35% more for a two-sided veneer.

uPVC sliding doors:

The Customer pays 5-10% more for a one-sided veneer and 10-15% more for a two-sided veneer.

The presented price offer is for information purposes only. If you want to know the detailed quote on your individual order, please contact our Sales Team. We will get back to you with the final price that is tailored to your specific needs – free of charge!

Fixed window

Size:	1000 x 1000
Double-glazed Price from:	€ 96 net
Triple-glazed Price from:	€ 120 net

Tilt and turn window

Size:	1000 x 1000
Double-glazed Price from:	€ 160 net
Triple-glazed Price from:	€ 181 net

Double sash tilt and turn window

Size:	1000 x 1000
Double-glazed Price from:	€ 236 net
Triple-glazed Price from:	€ 253 net
